Output Power

Hot Fudge 1x10 - 15W (6V6s)
Hot Fudge w/Nuts 1x12 - 20W (6V6s) or 35W (6L6s or EL34s).

Tube Compliment

Hot Fudge 1x10 - GZ34, (2)-6V6 or 6L6, (2)-12AX7
Hot Fudge w/Nuts 1x12 - GZ34, (2)-6V6, 6L6 or EL34, (3)-12AX7.

Class

AB push-pull with adjustable fixed bias.

Equalization

Single TONE control plus DEEP switch.

Vibrato

Power tube bias modulation type vibrato (no opticoupler) with all tube circuitry.

Chassis

Aluminum chassis.

Potentiometers

Full-size (15/16") chassis-mount with 3/8" bushing, solid metal shaft, damped action.

Circuitry

Hand-wired point-to-point with tinned solid-core PVC wiring, G-10 glass epoxy circuit board with brass eyelets. Carbon film resistors, Mallory M150 and CDM silver mica tone capacitors, Switchcraft jacks, Carling switches, and U.S. made molded type sockets.

Transformers

Hot Fudge 1x10 uses the Allen TP25, TO25 transformer set and TC choke. Hot Fudge w/Nuts 1x12 uses the Allen TP25 and TO35 transformer set and TC choke. See the TRANSFORMERS page for details.

Topology

Hot Fudge 1x10 is 6G2 (brown Princeton™) inspired but enhanced with DEEP switch, adjustable fixed bias with measurement jacks and bigger transformers.

Hot Fudge w/Nuts 1x12 is 6G3 (brown Deluxe™) inspired (long tailed pair phase inverter) but with 6G11 (brown Vibrolux™) vibrato plus all of the above mentioned enhancements.

Cabinet

Finger-jointed pine with British Cocoa Tolex and Custom Brown grill cloth. Rear screw-on back panels, rubber feet, steel reinforced rubber strap handle with chrome caps and bottom chrome corners. Brushed brass logo and black or cream barrel knobs.

Speaker

Hot Fudge 1x10 - Eminence Copperhead 10".
Hot Fudge w/Nuts 1x12 - Eminence Red, White and Blues 1x12.

Special Features

Deep switch adds a 50uf cathode bypass capacitor in parallel with the .68uf capacitor for the first gain stage. The 50uf cap is more Fenderish while the .68uf is more Marshall like. Rear bias measurement jacks plus adjustment pot for easy biasing with a voltmeter. Extension speaker jack. Choke filtered power supply. Aluminum chassis is non magnetic for quieter operation and will never rust.

Power Cord

Black, 12-foot, 3-prong grounded heavy-duty 18/3 with strain relief bushing.

Power Switches

Rear mounted POWER and STANDBY toggle switches.

Indicator Light

Front panel pilot-light for AC power with choice of red, green, blue, amber, or purple jeweled lens and #47 bulb.

Size and Weight

1x10 Combo - 20"W x 16"H x 9-3/4"D, 31 lbs.
1x12 Combo - 20"W x 20"H x 9-3/4"D, 35 lbs.
Head - 20"W x 10"H x 9-1/2"D, 22 lbs.

Price

Hot Fudge Chassis Only

$1,249

Hot Fudge Head

$1,399

Hot Fudge 1x10 Combo

$1,499

Hot Fudge 1x12 Combo

$1,549



Hot Fudge w/Nuts Chassis Only

$1,349

Hot Fudge w/Nuts Head

$1,499

Hot Fudge w/Nuts 1x12 Combo

$1,599

Options:

Other Tolex and grill cloth options available at no extra charge

Chrome 1-button footswitch for the vibrato

$40


Now available in kit form! See the Amp Kits page.


Matching speaker cabinets available too! See the Cabinets page.
